VHT47M50
$ 0.506

VHT47M50 Datasheet PDF - NTE Electronics

Manufacturer:
NTE Electronics
Category:
Aluminum Electrolytic Capacitors
Case Package:
Radial, CAN
Description:
Cap Aluminum Lytic 47uF 50V 20% (8 X 11.5mm) Radial 3.5mm 1000H 105℃
Pictures:
3D Model
Symbol
Footprint
Pinout
Product Pictures
VHT47M50 Datasheet PDF (2 Pages)
View Datasheet
Click page to view the detail

VHT47M50 Specifications

TYPE
DESCRIPTION
Number of Pins
2 Pin
Voltage Rating (DC)
50.0 V
Capacitance
47 µF
Capacitance Tolerance
±20 %
Case/Package
Radial, CAN
Pin Pitch
3.5 mm
Operating Temperature (Max)
105 ℃
Operating Temperature (Min)
-40 ℃
Voltage Rating
50 V

VHT47M50 Size & Package

TYPE
DESCRIPTION
Product Lifecycle Status
Active
Packaging
Each
Size-Height
11.5 mm
Size-Diameter
8.00 mm
Dielectric Material
Aluminum Electrolytic
Operating Temperature
-40℃ ~ 105℃
Life (Hours)
1000h @105℃

VHT47M50 Documents

VHT47M50 Other Datasheet PDF
NTE Electronics
2 Pages / 1.17 MByte
