STL6N2VH5 Datasheet PDF - ST Microelectronics

Manufacturer:

ST Microelectronics

Category:

MOSFETs

Case Package:

PowerFLAT-6

Description:

Power N-CH 20V 6A

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

STL6N2VH5 Datasheet PDF (12 Pages)

View Datasheet

Click page to view the detail

STL6N2VH5 Specifications

TYPE

DESCRIPTION

Mounting Style

Surface Mount

Number of Pins

6 Pin

Case/Package

PowerFLAT-6

Number of Channels

1 Channel

Polarity

N-CH

Power Dissipation

2.4 W

Threshold Voltage

0.7 V

Drain to Source Voltage (Vds)

20 V

Continuous Drain Current (Ids)

Input Capacitance (Ciss)

550pF @16V(Vds)

Input Power (Max)

2.4 W

Operating Temperature (Max)

150 ℃

Operating Temperature (Min)

-55 ℃

Power Dissipation (Max)

2.4W (Tc)

STL6N2VH5 Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Active

Packaging

Tape & Reel (TR)

Size-Length

2.1 mm

Size-Width

2.1 mm

Size-Height

0.75 mm

Operating Temperature

-55℃ ~ 150℃ (TJ)

STL6N2VH5 Environmental

STL6N2VH5 Function Overview

STL6N2VH5 Documents

STL6N2VH5 Other Datasheet PDF

ST Microelectronics

12 Pages / 0.48 MByte

STL6N2VH5 Packaging

ST Microelectronics

14 Pages / 0.87 MByte

STL6N2 Documents

STL6N2VH5 Datasheet PDF

ST Microelectronics

Power N-CH 20V 6A
