Part Datasheet Search > Through-Hole Resistors > VISHAY > RWM062222R0JA15E1 Datasheet PDF
RWM062222R0JA15E1
$ 0.715

RWM062222R0JA15E1 Datasheet PDF - VISHAY

Manufacturer:
VISHAY
Category:
Through-Hole Resistors
Case Package:
Axial
Description:
22Ω ±5% 7W ±75ppm/℃ Φ6.50mm
Pictures:
3D Model
Symbol
Footprint
Pinout
Product Pictures
Documentation:
RWM062222R0JA15E1 Datasheet (4 Pages)
RWM062222R0JA15E1 Datasheet PDF (4 Pages)
View Datasheet
Click page to view the detail

RWM062222R0JA15E1 Specifications

TYPE
DESCRIPTION
Mounting Style
Through Hole
Capacitance Tolerance
±5 %
Case/Package
Axial
Power Rating
7 W
Part Family
RWM
Resistance
22 Ω
Resistance Tolerance
±5 %
Voltage Rating
350 V
View Datasheet >

RWM062222R0JA15E1 Size & Package

TYPE
DESCRIPTION
Size-Length
18 mm
Size-Diameter
Φ6.50mm
Lead Length
25 mm
Temperature Coefficient
±75 ppm/℃
View Datasheet >

RWM062222R0JA15E1 Documents

RWM062222R0JA15E1 Datasheet
VISHAY
4 Pages / 0.08 MByte

RWM062222R0JA15 Documents

RWM062222R0JA15E1 Datasheet PDF
VISHAY
22Ω ±5% 7W ±75ppm/℃ Φ6.50mm
RWM062222R0JA15E1 Datasheet PDF
Vishay Semiconductor
VISHAY RWM062222R0JA15E1 Through Hole Resistor, 22Ω, 350V, Axial Leaded, 6W, ± 5%, RWM Series
RWM062222R0JA15E1 Datasheet PDF
Vishay Sfernice
Through Hole Wirewound Resistor, RWM Series, 22Ω, 6W, - 5%, 350V, Axial Leaded
RWM062222R0JA15E1 Datasheet PDF
Vishay Spectrol
Resistor; Wirewound; Res 22Ω; Pwr-Rtg 7W; Tol 5%; Axial; Vitreous Enamel
